Standard Duty · 50 lb capacity
Save your back — roll your whole telescope outside in one trip.
The JMI Medium Universal Wheeley Bar is the easy, fast way to move a fully assembled tripod-mounted telescope from storage to your observing spot — no disconnecting mount cables, cameras, or power between sessions. Lock the wheels, level the base on its built-in leveling bolts, and start observing. Built on a sturdy welded-steel frame by JMI (part of the CXB Astro family) and made in the USA.
This is our standard-duty Universal model, sized for lighter visual and grab-and-go rigs. If your fully loaded setup exceeds 50 lb, choose one of our Heavy-Duty Universal Wheeley Bars instead (rated to 300 lb).
Specifications
Maximum load
50 lb total — tripod, mount, OTA, and all accessories combined
Tip-to-tip distance
32.3″ – 36.8″
Tripod tip receptacle
2-1/4″ I.D. — fits tripod feet up to 2″
Standard package
2-3/8″ locking caster wheels + 1/2″ leveling screws
Construction
Welded steel, locking wheels, leveling bolts. Made in USA.
Best for
Lighter visual rigs and grab-and-go setups under 50 lb
Which Wheeley Bar Size Fits Your Tripod?
Measure your tripod’s tip-to-tip distance at observing height, then match it to a model below. This standard-duty Medium suits lighter rigs up to 50 lb; the heavy-duty models all carry up to 300 lb.
Model
Capacity
Tip-to-tip range
Medium (Standard)This model
50 lb
32.3″ – 36.8″
HD Shorty
300 lb
26.25″ – 31.25″*
HD Medium
300 lb
34″ – 42.5″
HD Large
300 lb
49″ – 56.5″
*HD Shorty minimum tip-to-tip is 28.25″ when configured with 10″ pneumatic tires. Over 50 lb? Step up to a Heavy-Duty model.
Configure & Upgrade Your Wheeley Bar
The base Wheeley Bar ships ready to roll on hard, flat surfaces. Add the upgrades that match where and how you observe — all available in our Wheeley Bar Accessories collection:
5″ Polyurethane Wheels
Smoother ride over cracked concrete, sidewalk seams, and rough pavement. Raises the setup ~6″.
10″ Pneumatic Tires + Tow Handle
All-terrain wheels for grass, dirt, and gravel. Raises the setup ~3.5″.
Tie-Down Bracket Kit
Secures and stabilizes your mount to the Wheeley Bar. Recommended for every setup.
Recommended: add the full Tie-Down Bracket Kit to lock your telescope securely to the Wheeley Bar — especially important when moving over uneven ground.
Made in the USA
Every JMI Wheeley Bar is welded, assembled, and tested in the USA — click to watch how they’re built (the video also plays in the product gallery above).
Frequently Asked Questions
What is tip-to-tip distance, and how do I measure it?
Tip-to-tip distance is the spread between two of your tripod’s feet at observing height — it’s how you confirm your tripod fits a given Wheeley Bar. To measure:
1. Set your tripod to observing height (comfortable eyepiece height for visual; as low as practical for imaging stability).
2. Lower the tripod ~6″ if you'll run 5″ polyurethane wheels, or ~3.5″ if you'll run 10″ pneumatic tires — this accounts for the lift the Wheeley Bar adds.
3. Measure between any two tripod tips. Match that number to the comparison table above (32.3″–36.8″ for this Medium model).
Which wheels should I choose?
The standard 2-3/8″ wheels work on smooth, hard, flat surfaces. For cracked concrete, sidewalk seams, or rough pavement, the 5″ polyurethane upgrade rides much smoother. For grass, dirt, or gravel, use the 10″ all-terrain pneumatic tires — take care on soft or wet ground, where the tires can sink in.
Will it fit through my doorway?
With the 10″ large-wheel upgrade, your doorway must be at least 3″ wider than your tip-to-tip distance. For swiveling-caster models, the widest point is measured to the outside corners of the legs/leveling screws (about 3″ wider than tip-to-tip); the narrowest point — one leg end to the inside of the opposite side — tells you the tightest door you could wiggle through. The layout drawings below show these measurements clearly.
Layout Drawings
Not sure which Wheeley Bar is right for you?
Compare every model and walk through the full sizing guide.
